  Solid Carbide Burrs


   SHAPE A : Cylindrical-Standare



Tool number Head diameter Length of cut Shank diameter Total length
SA-11 1/8" 1/2" 1/4" 2-1/4"
SA-12 1/8" 5/8" 1/4" 2-3/8"
SA-13 5/32" 5/8" 1/4" 2-3/8"
SA-14 3/16" 5/8" 1/4" 2-3/8"
SA-1 1/4" 5/8" 1/4" 2-3/8"
SA-1L 1/4" 1" 1/4" 2-3/4"
SA-2 5/16" 3/4" 1/4" 2-9/16"
SA-3 3/8" 3/4" 1/4" 2-9/16"
SA-4 7/16" 1" 1/4" 2-3/8"
SA-5 1/2" 1" 1/4" 2-3/8"
SA-6 5/8" 1" 1/4" 2-3/8"
SA-7 3/4" 1" 1/4" 2-3/8"
SA-8 7/8" 1"  1/4" 2-3/8"
SA-9 1" 1" 1/4" 2-3/8"


   SHAPE A : Cylindrical-Metric



Tool number Head diameter Length of cut Shank diameter Total length
A0312 3mm 12mm 6/6.35mm 57mm
A0316 3mm 16mm 6/6.35mm 61mm
A0416 4mm 16mm 6/6.35mm 61mm
A0516 5mm 16mm 6/6.35mm 61mm
A0616 6mm 16mm 6/6.35mm 61mm
A0625 6mm 25mm 6/6.35mm 70mm
A0820 8mm 20mm 6/6.35mm 65mm
A1020 10mm 20mm 6/6.35mm 65mm
A1125 11mm 25mm 6/6.35mm 70mm
A1225 12mm 25mm 6/6.35mm 70mm
A1625 16mm 25mm 6/6.35mm 70mm
A1925 19mm 25mm 6/6.35mm 70mm
A2225 22mm 25mm 6/6.35mm 70mm
A2525 25mm 25mm 6/6.35mm 70mm
